CABLE SLEEVE Kit 2/10/25 mt diameter 6-20mm Expandable red polyester

CABLE SLEEVE KIT 2/10/25 Meters diameter 6-20mm Expandable Red Polyester

You can choose the length of your conduit, the 6-20mm can accommodate cable diameters (not cross section) from 6 to 20mm, however to allow easy installation it is recommended for cables with a maximum diameter of 13/14mm equal to an average cross section of 25/35mmq. check with a gauge the outer diameter of your cable if you have any doubts.

Remember that the closer the diameter of your cable is to the maximum sheathing diameter, the more it will expand as it shortens, so on average if your power cable is 4.5 meters long you need to buy 6 meters of sheathing at least. Also, to avoid fraying after cutting it is advisable to "burn and melt" the cutting end with a lighter to weld the fibers together.

Expandable polyester sheathing Red color.

Flame retardant and halogen-free.

They offer excellent abrasion resistance for many industrial uses. The special weave makes them easy to install.

Working temperature range of -50°C to +150°C.

Melting point at 250°C.

UL, CSA, RoHS, PFOS, REACH certified.

Available for purchase in kits of 2-10-25 meters or in whole coils.

(Images are for the sole purpose of presenting the product. With the purchase of a few meters of conduit you will get a smaller roll of conduit than the coil pictured at home)
