GS AUDIO COMPACT SQ GS-190.4CMP - 4*190Wrms @2ohm

Name: GS AUDIO COMPACT SQ GS-190.4CMP - 4*190Wrms @2ohm
Brand: GS AUDIO
SKU: GS 4.190CMP
Price: 179 EUR
Availability: InStock

€179.00 €146.72

In stock

SKU

GS 4.190CMP

Shipping time: Ready within 24 hours

Spedisci a: / Ship to:

Calcola / Ceck Shipping Cost

Qty

Add to Compare

GS AUDIO COMPACT SQ GS-190.4CMP - 4*190Wrms @2ohm is available to buy in increments of 1

Details

GS AUDIO COMPACT SQ GS-190.4CMP / 4*190Wrms @2ohm / 2*320Wrms @4ohm

The new line of Gs Audio Compact Sound Quality series amplifiers are the evolution of the previous Sound Quality series.

These latest generation class D amplifiers thanks to new integrated circuits are able to offer excellent timbre and sound clarity, in addition new IGBT Power Transistors with low thermal dissipation have allowed to reduce the chassis in weight and size offering similar overall dimensions to "Brazilian" amplifiersbut superior control over the loudspeaker.

Due precisely to the sound qualities, a smaller size than the preceding GS Sound Quality series we named this series SQ Compact (Sound quality compact).

All 3 models currently available, the 4-channel model 190.4, the mono channel 550.1 and the two-channel model 280.2 have RCA and high level inputs that allow them to be perfectly adapted even to audio system with standard car radios.

Audio adjustments are arranged frontally instead of sideways for easier access in case of installation in places with poor lighting and visibility.

As you can see from the internal photos these amplifiers have nothing to do with modern Brazilian digital, round toroids instead of square and large capacitors in addition to vertically placed control boards help to minimize background noise and disturbances, polyester capacitors at the input and output filter out any hum from the power supply, and to complete the power supply terminal blocks are sized to accommodate a cable up to 35mmq!

GS 190.4CMP model powers:

4*110Wrms @ 4 ohms

4*190Wrms @ 2 ohms

bridge mode: 2*320Wrms @ 4 ohm

trimode: 2*110Wrms @4 ohm + 1*320Wrms @ 4 ohm

trimode: 2*190Wrms @2 ohm + 1*320Wrms @ 4 ohm

For those using the amplifier with internal active filters without a processor, here are the frequency cutoffs:

separate for channels 1-2 and 3-4

LPF: 50hz to 500Hz (can be turned off)

HPF: 50hz to 2000Hz (can be turned off)

The amplifier comes complete with screws, allen wrenches, stickers.

The complete installation manual is not included in the box but can be downloaded at the links below
